How Multi-Stream of QUIC Could Mitigate the HOL Blocking Issue of MQTT Connection
William
Table of Contents
HOL Blocking Issues in MQTT Communication
In traditional solutions, all MQTT messages are sent through a single channel between the MQTT client and server. For TCP, this means using one TCP connection; for TCP/TLS, it involves a single TLS connection; and for the QUIC solution, it refers to the sole QUIC stream within a QUIC connection.
All messages are queued for sequential sending, meaning that the message at the front of the queue blocks all subsequent messages until it is transmitted. This type of blocking can cause high-priority data to be delayed if a low-priority message is at the front of the queue. Additionally, if a large message does not finish transmitting within a certain period—known as the keepalive interval—the connection may be disconnected. However, this is not the end of the story; the client can reconnect and attempt to retransmit the large message. Unfortunately, it is likely to time out again, resulting in the client getting stuck in a reconnect loop.
In summary, head-of-line (HOL) blocking prevents important high-priority messages from reaching the intended recipient on time and can also lead to repeated reconnect attempts. This causes an unstable connection and will be hard to detect without looking into the on-wire messaging.
The Multi-Stream Feature of MQTT over QUIC
The multi-stream feature of MQTT over QUIC in EMQX can solve the problem. Between a client and EMQX MQTT broker, there is one QUIC connection that supports multiple streams. We send different messages over these streams and assign varying priority levels to them. This allows the QUIC stack to manage the network transmission effectively, helping to mitigate the HOL blocking issue. In this way, low-priority large messages won't obstruct the transmission of smaller, more important messages.
However, there's a trade-off regarding message ordering: while message ordering is guaranteed within a single stream, it is not assured across different streams. Typically, this is not a major concern because when one message has a higher priority than another, it is generally expected that the high-priority message should take precedence. Therefore, while ordering is not critical among messages of different priorities, maintaining the correct prioritization is essential.
This blog explores how the MQTT over QUIC multi-stream feature can mitigate the HOL blocking issue, improve data exchange, and reduce disconnections.
The Test: How Multi-Stream Solves HOL Blocking Issue
In order to find out how MQTT over stream multi-stream feature could help here, we designed the following tests.
Test Overview
Producer:
It produces data for two topics, for a glance at definitions:
{ "topics" : [ {"name": "Topic1", "interval_ms": "100", "inject_timestamp" : true, "QoS": 1, "payload_encoding": "eterm", "payload": {"foo1" : "bar1", "timestamp": "0", "Data": "10"}, "stream" : 0, "stream_priority": 200, }, {"name": "Topic2", "interval_ms": "5000", "inject_timestamp" : "ms", "QoS": 1, "payload_encoding": "eterm", "payload": {"foo2" : "bar2", "timestamp": "0", "VIN" : "VIN", "Data": "%p25000"}, "stream" : 0, "stream_priority": 8, "render": "Data", } ] }The messages for
Topic1are small messages under 1k that are sent 10 times per second. These messages have a higher priority of200.The messages for
Topic2consist of large messages (25k pages, totaling 100 MB), sent every 5 seconds.The producer operates in an area with a poor network connection, which only allows for approximately 30 IP packets per second.
Consumer:
We have one consumer only listening on the topic
Topic1,which will be most interested to see how much gets delivered.The consumer stays in a good network without any network faults or rate limitings.
Test Setup:
Producer <---- rate limit 30 pks/sec ----> | EMQX | <--- Good network ---> Consumer
iptables is used to inject ratelimit:
-N RATE_LIMIT -A INPUT -i veth0 -j RATE_LIMIT -A RATE_LIMIT -m limit --limit 29/sec -j ACCEPT -A RATE_LIMIT -j DROP
Test 1: TCP/TLS Single Stream
Producer Results:
Publishing stopped after 6s; that is when the 'big message' kicks in.
The connection gets closed after 2 mins.
./emqtt_bench pub --topics-payload ./topic_spec.json -c 1 -h 192.168.200.1 -F 1000 -k 60 -S -p 8883 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s pub total=8 rate=2.84/sec 1s connect_succ total=1 rate=0.36/sec 2s pub total=18 rate=10.06/sec 3s pub total=28 rate=9.69/sec 4s pub total=38 rate=10.25/sec 5s pub total=48 rate=9.97/sec 6s pub total=49 rate=1.01/sec client(1): EXIT for {shutdown,closed} 2m1s pub_fail total=2 rate=0.02/secConsumer Results:
It only gets 49 messages from 'Topic1' delivered in total.
./emqtt_bench sub -c 1 -t Topic1 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s sub total=1 rate=0.98/sec 1s connect_succ total=1 rate=0.98/sec 13s recv total=4 rate=0.31/sec 14s recv total=14 rate=9.95/sec 15s recv total=24 rate=10.02/sec 16s recv total=34 rate=9.56/sec 17s recv total=44 rate=10.26/sec 18s recv total=49 rate=4.98/sec
Test 2: QUIC Single Stream
Producer Results:
Almost the same as TCP/TLS, the publishing is stopped after 6s when the 'big message' kicks in.
BUT, it is NOT due to the QUIC connection being closed; rather, it stems from the MQTT protocol layer's keep-alive timeout, and in this test, we have set keepalive timeout to 60s. EMQX decided to shut down the MQTT connection, and the client received an MQTT.DISCONNECT message from QUIC. There is nothing wrong with the QUIC connection itself; the real problem is the Head-of-Line (HOL) blocking that prevents the large message from being delivered in time to maintain the keep-alive deadline on the EMQX side. How sad!
./emqtt_bench pub --topics-payload ./topic_spec.json -c 1 -h 192.168.200.1 -F 1000 -k 60 --quic -p 14567 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s pub total=8 rate=2.53/sec 1s connect_succ total=1 rate=0.32/sec 2s pub total=18 rate=10.00/sec 3s pub total=28 rate=10.00/sec 4s pub total=37 rate=8.95/sec 5s pub total=47 rate=10.06/sec 6s pub total=49 rate=2.00/sec client(1): disconnected with reason 141: keepalive_timeout 2m1s pub_fail total=1175 rate=9.54/secConsumer Results:
Same as the above tests, the consumer received 49 messages.
./emqtt_bench sub -c 1 -t Topic1 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s sub total=1 rate=0.96/sec 1s connect_succ total=1 rate=0.96/sec 11s recv total=6 rate=0.54/sec 12s recv total=15 rate=9.14/sec 13s recv total=26 rate=10.88/sec 14s recv total=36 rate=10.04/sec 15s recv total=46 rate=10.08/sec 16s recv total=49 rate=2.99/sec
Test 3: MQTT over QUIC, Multi Streams
It’s worth noting that, unlike the previous tests, we specified that Topic1 will use stream 1, while Topic2 will use stream 2. stream 1 has a higher priority than stream 2, but the other settings remain the same. Additionally, we have a default control stream: stream 0, which is used for sending MQTT.PINGREQ messages. This stream has the highest priority and helps keep the MQTT connection alive. In the earlier QUIC single stream test, stream 0 was the only one used and served as the default stream.
{
"topics" : [
{"name": "Topic1",
"interval_ms": "100",
"inject_timestamp" : true,
"QoS": 1,
"payload_encoding": "eterm",
"payload": {"foo1" : "bar1", "timestamp": "0", "Data": "10"},
"stream" : 1,
"stream_priority": 200,
},
{"name": "Topic2",
"interval_ms": "5000",
"inject_timestamp" : "ms",
"QoS": 1,
"payload_encoding": "eterm",
"payload": {"foo2" : "bar2", "timestamp": "0", "VIN" : "VIN", "Data": "%p25000"},
"stream" : 2,
"stream_priority": 8,
"render": "Data",
}
]
}
Producer Results:
Publishing with small resistance.
./emqtt_bench pub --topics-payload ./topic_spec.json -c 1 -h 192.168.200.1 -F 1000 -k 60 --quic -p 14567 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s pub total=8 rate=3.08/sec 1s connect_succ total=1 rate=0.39/sec 2s pub total=18 rate=10.00/sec 3s pub total=28 rate=9.99/sec 4s pub total=38 rate=10.05/sec 5s pub total=48 rate=9.88/sec 6s pub total=56 rate=7.96/sec 7s pub total=68 rate=12.12/sec 8s pub total=78 rate=9.54/sec 9s pub total=88 rate=10.58/sec 10s pub total=98 rate=9.88/sec 11s pub total=108 rate=9.79/sec 12s pub total=118 rate=10.21/sec 13s pub total=128 rate=10.12/sec 14s pub total=138 rate=10.00/sec 15s pub total=147 rate=8.81/sec 16s pub total=156 rate=9.20/sec 17s pub total=165 rate=8.92/sec 18s pub total=178 rate=13.00/sec 19s pub total=187 rate=9.08/sec 20s pub total=198 rate=10.79/sec 21s pub total=208 rate=9.93/sec 22s pub total=218 rate=10.27/sec 23s pub total=228 rate=10.00/sec 24s pub total=237 rate=8.86/sec 25s pub total=248 rate=11.18/sec 26s pub total=258 rate=10.00/sec 27s pub total=267 rate=8.69/sec 28s pub total=278 rate=11.39/sec 29s pub total=288 rate=9.92/sec 30s pub total=298 rate=10.08/sec 31s pub total=308 rate=9.61/sec 32s pub total=317 rate=9.40/sec 33s pub total=328 rate=10.87/sec 34s pub total=338 rate=10.11/sec 35s pub total=348 rate=9.76/sec 36s pub total=358 rate=10.18/sec 37s pub total=368 rate=10.07/sec 38s pub total=377 rate=8.88/sec 39s pub total=388 rate=11.09/sec 40s pub total=398 rate=10.06/sec 41s pub total=406 rate=8.00/sec 42s pub total=417 rate=11.00/sec 43s pub total=428 rate=10.92/sec 44s pub total=436 rate=8.06/sec 45s pub total=448 rate=11.71/sec 46s pub total=458 rate=10.20/sec 47s pub total=468 rate=10.02/sec 48s pub total=477 rate=9.02/sec 49s pub total=488 rate=10.90/sec 50s pub total=498 rate=9.99/sec 51s pub total=507 rate=8.69/sec 52s pub total=518 rate=11.33/sec 53s pub total=526 rate=8.12/sec 54s pub total=538 rate=11.58/sec 55s pub total=548 rate=10.35/sec 56s pub total=556 rate=7.89/sec 57s pub total=568 rate=12.21/sec 58s pub total=578 rate=9.94/sec 59s pub total=587 rate=8.76/sec 1m0s pub total=598 rate=11.34/sec 1m1s pub total=607 rate=8.97/sec 1m2s pub total=617 rate=10.08/sec 1m3s pub total=627 rate=9.88/sec 1m4s pub total=636 rate=9.09/sec 1m5s pub total=648 rate=11.73/sec 1m6s pub total=658 rate=10.20/sec 1m7s pub total=667 rate=9.04/sec 1m8s pub total=678 rate=11.01/sec 1m9s pub total=687 rate=9.00/sec 1m10s pub total=696 rate=8.87/sec 1m11s pub total=708 rate=11.92/sec 1m12s pub total=718 rate=10.22/sec 1m13s pub total=728 rate=9.81/sec 1m14s pub total=738 rate=10.19/sec 1m15s pub total=748 rate=9.88/sec 1m16s pub total=758 rate=10.01/sec 1m17s pub total=768 rate=9.91/sec 1m18s pub total=777 rate=9.15/sec 1m19s pub total=788 rate=10.97/sec 1m20s pub total=798 rate=9.98/sec 1m21s pub total=807 rate=9.08/sec 1m22s pub total=818 rate=11.00/sec 1m23s pub total=828 rate=10.00/sec 1m24s pub total=836 rate=8.00/sec 1m25s pub total=847 rate=10.89/sec 1m26s pub total=857 rate=10.04/sec 1m27s pub total=864 rate=6.86/sec 1m28s pub total=878 rate=13.93/sec 1m29s pub total=888 rate=9.96/sec 1m30s pub total=897 rate=9.31/sec 1m31s pub total=907 rate=10.00/sec 1m32s pub total=917 rate=9.78/sec 1m33s pub total=928 rate=10.99/sec 1m34s pub total=938 rate=10.16/sec 1m35s pub total=947 rate=8.87/sec 1m36s pub total=957 rate=10.27/sec 1m37s pub total=967 rate=9.96/sec 1m38s pub total=978 rate=11.02/sec 1m39s pub total=988 rate=9.94/sec 1m40s pub total=998 rate=9.43/sec 1m41s pub total=1008 rate=10.70/sec 1m42s pub total=1016 rate=8.00/sec 1m43s pub total=1028 rate=11.85/sec 1m44s pub total=1038 rate=10.16/sec 1m45s pub total=1048 rate=9.92/sec 1m46s pub total=1056 rate=7.87/sec 1m47s pub total=1067 rate=11.25/sec 1m48s pub total=1077 rate=9.81/sec 1m49s pub total=1088 rate=10.87/sec 1m50s pub total=1098 rate=10.35/sec 1m51s pub total=1108 rate=9.62/sec 1m52s pub total=1118 rate=10.32/sec 1m53s pub total=1128 rate=10.06/sec 1m54s pub total=1137 rate=9.03/sec 1m55s pub total=1148 rate=10.95/sec 1m56s pub total=1157 rate=8.97/sec 1m57s pub total=1168 rate=10.92/sec 1m58s pub total=1178 rate=10.14/sec 1m59s pub total=1188 rate=9.98/sec 2m0s pub total=1198 rate=9.54/sec 2m1s pub total=1207 rate=9.32/sec 2m2s pub total=1218 rate=11.19/sec 2m3s pub total=1228 rate=9.91/sec 2m4s pub total=1237 rate=9.08/sec 2m5s pub total=1246 rate=9.00/sec 2m6s pub total=1257 rate=10.89/sec 2m7s pub total=1268 rate=10.78/sec 2m8s pub total=1277 rate=9.20/sec 2m9s pub total=1288 rate=10.97/sec 2m10s pub total=1298 rate=10.02/sec 2m11s pub total=1308 rate=10.09/sec 2m12s pub total=1318 rate=9.86/sec 2m13s pub total=1328 rate=10.14/sec 2m14s pub total=1338 rate=10.00/sec 2m15s pub total=1347 rate=8.96/sec 2m16s pub total=1357 rate=10.02/sec 2m17s pub total=1368 rate=10.87/sec 2m18s pub total=1375 rate=7.11/sec 2m19s pub total=1388 rate=12.97/sec 2m20s pub total=1398 rate=9.83/sec 2m21s pub total=1408 rate=9.58/sec 2m22s pub total=1417 rate=9.48/sec 2m23s pub total=1428 rate=11.13/sec 2m24s pub total=1438 rate=10.00/sec 2m25s pub total=1448 rate=9.73/sec 2m26s pub total=1458 rate=10.21/sec 2m27s pub total=1468 rate=9.86/sec 2m28s pub total=1477 rate=9.00/sec 2m29s pub total=1488 rate=11.22/secConsumer Results:
The consumer should be happy this time.
./emqtt_bench sub -c 1 -t Topic1 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s sub total=1 rate=0.98/sec 1s connect_succ total=1 rate=0.98/sec 15s recv total=6 rate=0.40/sec 16s recv total=15 rate=8.95/sec 17s recv total=25 rate=10.00/sec 18s recv total=35 rate=10.06/sec 19s recv total=45 rate=9.99/sec 20s recv total=54 rate=8.99/sec 21s recv total=65 rate=10.77/sec 22s recv total=75 rate=9.89/sec 23s recv total=85 rate=10.22/sec 24s recv total=95 rate=10.12/sec 25s recv total=105 rate=10.00/sec 26s recv total=114 rate=9.00/sec 27s recv total=125 rate=10.50/sec 28s recv total=135 rate=10.42/sec 29s recv total=145 rate=10.01/sec 30s recv total=154 rate=9.06/sec 31s recv total=165 rate=10.86/sec 32s recv total=175 rate=9.78/sec 33s recv total=185 rate=10.34/sec 34s recv total=194 rate=8.98/sec 35s recv total=204 rate=9.99/sec 36s recv total=215 rate=11.03/sec 37s recv total=224 rate=8.96/sec 38s recv total=233 rate=8.93/sec 39s recv total=244 rate=11.07/sec 40s recv total=255 rate=11.00/sec 41s recv total=265 rate=9.86/sec 42s recv total=275 rate=10.21/sec 43s recv total=284 rate=9.00/sec 44s recv total=295 rate=11.01/sec 45s recv total=303 rate=7.80/sec 46s recv total=315 rate=12.06/sec 47s recv total=325 rate=10.15/sec 48s recv total=334 rate=9.04/sec 49s recv total=345 rate=10.99/sec 50s recv total=355 rate=10.03/sec 51s recv total=365 rate=9.99/sec 52s recv total=375 rate=9.97/sec 53s recv total=385 rate=10.04/sec 54s recv total=395 rate=10.00/sec 55s recv total=405 rate=10.00/sec 56s recv total=415 rate=9.94/sec 57s recv total=425 rate=10.05/sec 58s recv total=434 rate=8.90/sec 59s recv total=445 rate=11.01/sec 1m0s recv total=455 rate=10.00/sec 1m1s recv total=465 rate=9.99/sec 1m2s recv total=475 rate=10.12/sec 1m3s recv total=485 rate=10.00/sec 1m4s recv total=494 rate=9.00/sec 1m5s recv total=505 rate=11.00/sec 1m6s recv total=515 rate=9.93/sec 1m7s recv total=525 rate=10.03/sec 1m8s recv total=535 rate=10.00/sec 1m9s recv total=545 rate=10.00/sec 1m10s recv total=555 rate=9.88/sec 1m11s recv total=565 rate=10.16/sec 1m12s recv total=575 rate=9.67/sec 1m13s recv total=585 rate=10.04/sec 1m14s recv total=594 rate=9.20/sec 1m15s recv total=604 rate=9.88/sec 1m16s recv total=615 rate=11.20/sec 1m17s recv total=625 rate=9.98/sec 1m18s recv total=635 rate=10.04/sec 1m19s recv total=645 rate=9.95/sec 1m20s recv total=655 rate=9.95/sec 1m21s recv total=663 rate=8.08/sec 1m22s recv total=675 rate=11.90/sec 1m23s recv total=684 rate=9.06/sec 1m24s recv total=694 rate=9.96/sec 1m25s recv total=704 rate=10.05/sec 1m26s recv total=715 rate=10.85/sec 1m27s recv total=725 rate=10.07/sec 1m28s recv total=735 rate=10.02/sec 1m29s recv total=745 rate=10.02/sec 1m30s recv total=754 rate=8.96/sec 1m31s recv total=765 rate=10.92/sec 1m32s recv total=775 rate=10.15/sec 1m33s recv total=785 rate=9.92/sec 1m34s recv total=795 rate=9.93/sec 1m35s recv total=805 rate=9.88/sec 1m36s recv total=814 rate=9.07/sec 1m37s recv total=823 rate=9.08/sec 1m38s recv total=835 rate=12.11/sec 1m39s recv total=843 rate=8.01/sec 1m40s recv total=855 rate=12.00/sec 1m41s recv total=864 rate=8.88/sec 1m42s recv total=875 rate=11.06/sec 1m43s recv total=885 rate=10.06/sec 1m44s recv total=895 rate=9.85/sec 1m45s recv total=905 rate=10.14/sec 1m46s recv total=915 rate=9.67/sec 1m47s recv total=925 rate=10.38/sec 1m48s recv total=935 rate=9.99/sec 1m49s recv total=945 rate=9.94/sec 1m50s recv total=955 rate=9.75/sec 1m51s recv total=965 rate=10.34/sec 1m52s recv total=974 rate=8.98/sec 1m53s recv total=985 rate=10.97/sec 1m54s recv total=995 rate=10.04/sec 1m55s recv total=1005 rate=10.01/sec 1m56s recv total=1014 rate=8.96/sec 1m57s recv total=1025 rate=10.82/sec 1m58s recv total=1035 rate=10.17/sec 1m59s recv total=1045 rate=9.87/sec 2m0s recv total=1055 rate=10.18/sec 2m1s recv total=1065 rate=9.60/sec 2m2s recv total=1075 rate=10.44/sec 2m3s recv total=1085 rate=9.92/sec 2m4s recv total=1095 rate=10.01/sec 2m5s recv total=1105 rate=10.03/sec 2m6s recv total=1115 rate=9.95/sec 2m7s recv total=1125 rate=10.09/sec 2m8s recv total=1135 rate=9.90/sec 2m9s recv total=1144 rate=8.96/sec 2m10s recv total=1155 rate=10.98/sec 2m11s recv total=1165 rate=10.11/sec 2m12s recv total=1175 rate=10.01/sec 2m13s recv total=1185 rate=9.95/sec 2m14s recv total=1195 rate=10.02/sec 2m15s recv total=1205 rate=10.07/sec 2m16s recv total=1215 rate=10.00/sec 2m17s recv total=1223 rate=7.96/sec 2m18s recv total=1235 rate=11.80/sec 2m19s recv total=1245 rate=10.21/sec 2m20s recv total=1254 rate=8.74/sec 2m21s recv total=1264 rate=10.29/sec 2m22s recv total=1275 rate=11.02/sec 2m23s recv total=1285 rate=10.01/sec 2m24s recv total=1295 rate=9.92/sec 2m25s recv total=1305 rate=10.02/sec 2m26s recv total=1315 rate=10.06/sec 2m27s recv total=1324 rate=9.00/sec 2m28s recv total=1335 rate=10.92/sec 2m29s recv total=1345 rate=10.01/sec 2m30s recv total=1355 rate=10.05/sec 2m31s recv total=1365 rate=9.98/sec 2m32s recv total=1374 rate=9.01/sec 2m33s recv total=1384 rate=10.01/sec 2m34s recv total=1395 rate=11.01/sec 2m35s recv total=1404 rate=9.00/sec 2m36s recv total=1415 rate=11.00/sec 2m37s recv total=1424 rate=8.98/sec 2m38s recv total=1433 rate=9.01/sec 2m39s recv total=1444 rate=10.81/sec 2m40s recv total=1455 rate=11.21/sec 2m41s recv total=1464 rate=8.85/sec 2m42s recv total=1475 rate=11.13/sec 2m43s recv total=1485 rate=9.98/sec 2m44s recv total=1495 rate=10.07/sec
Test 4: Raw TCP for Curious Readers
Producer:
./emqtt_bench pub --topics-payload ./topic_spec.json -c 1 -h 192.168.200.1 -F 1000 -k 60 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s pub total=9 rate=4.48/sec 1s connect_succ total=1 rate=0.50/sec 2s pub total=19 rate=9.97/sec 3s pub total=29 rate=10.04/sec 4s pub total=39 rate=10.05/sec 5s pub total=49 rate=9.16/sec client(1): EXIT for {shutdown,closed} 2m1s pub_fail total=2 rate=0.02/secConsumer:
./emqtt_bench sub -c 1 -t Topic1 Start with 6 workers, addrs pool size: 1 and req interval: 60 ms 1s sub total=1 rate=0.98/sec 1s connect_succ total=1 rate=0.98/sec 23s recv total=2 rate=0.09/sec 24s recv total=11 rate=9.33/sec 25s recv total=22 rate=10.95/sec 26s recv total=32 rate=10.09/sec 27s recv total=42 rate=9.95/sec 28s recv total=49 rate=7.06/sec
Last Word
Impressive right?
You may ask why Topic1 doesn’t look like gets blocked at all in multi-stream tests, and what happed to the Topic2 messages? How does QUIC balance these? This is all about how QUIC packages data from different streams, A QUIC packet could contain the data of stream 1, the data of stream 2, or BOTH! We will dig into that with the help of Wireshark trace and explain in the next blog post. Stay Tuned!
